LEDD
Features
- 5 independent diode drive channels
- High accuracy/resolution set points
- Web-based interface
- Ethernet connectivity
- Device temperature monitoring
Overview
Ice Bloc LED5 is a five channel precision diode driver optimised for LED applications. Designed for use either as a stand-alone instrument or OEM driver control for integrated systems, the web based user interface delivers flexible control of multichannel LED arrays. High accuracy and resolution current set points provide a stable output for biophotonic device and novel lighting control.
Specifications
| DIODE DRIVERS x 5 | |
|---|---|
| Maximum current range | 0 – 1000mA |
| Output current control range | 25 – 100% |
| Output voltage range | 2 – 48V |
| Max power per channel | 48W |
| Ripple and noise | 800mV pk-pk |
| Current setting resolution (theoretical) | 11.6uA |
| INTERFACE WITH LM94021 TEMPERATURE SENSOR | |
|---|---|
| Measurable temperature range | 10 – 100 degrees Celsius |
| GENERAL (LED DIODE DRIVER BOARD ONLY) | |
|---|---|
| Runs off | 48V 300W power supply |
| GENERAL (IF USED WITHIN ICEBLOC) | |
|---|---|
| Mains input voltage | 100 – 240 V AC, 50/60 Hz, 350 VA (typical power: 15 W) |
| Open circuit voltage | 3.3 V |
| Size (W x H x D) | Half rack (203mm) x 2U (89mm) x 345mm (8” x 3.5” x 13.6”) |
| Weight | 4.1 kg |
| Operating temperature | 0 °C to 70 °C |
| Output voltage | +5 V |
| Storage temperature | -20 °C – 85 °C |
| Relative humidity |
<90 % humidity, non-condensing |
| Indoor/outdoor use |
Indoor use only |
| Altitude | <2000 m |
